Elevator Specifications & Model Details
Resources
Details
Information
- External Cylinder Diameter: 37.75” (959mm)
- Rated Load: 500lb (227 kg)
- Capacity: 2-Passengers
- Travel: 2 - 4 Stops
- Total Rise: 38 ft
- Speed: 32 fpm
- Electrical: 220 V - 240V / 5A / Single Phase
- 110v Lighting Circuit
- Machinery: Dual Winding Drums
- Exterior: Aluminum Frame & Polycarbonate Panels
- Minimum Floor to Floor Height: 93.5” (2375mm)
- Minimum Floor Ceiling Height: 81” (2057 mm)
- Minimum Overhead: 105” (2667mm)
- Cabin Entrance Width: 23.5” (597mm)
- Internal Cabin Height: 79” (2007 mm)
- Internal Cabin Diameter: 32” (813mm)
- External Cylinder Diameter: 53.5” (1359mm)
- Rated Load: 825lb (408 kg)
- Capacity: 3-Passengers
- Travel: 2 - 4 Stops
- Total Rise: 38 ft
- Speed: 32 fpm or 40 fpm
- Electrical: 220 V - 240V / 8A / Single Phase
- 110v Lighting Circuit
- Machinery: Dual Winding Drums
- Exterior: Aluminum Frame & Polycarbonate Panels
- Minimum Floor to Floor Height: 93.5” (2375mm)
- Minimum Floor to Floor Height: 96.5” (2451mm)
- *Speed Package Installed
- Minimum Floor Ceiling Height: 83” (2108 mm)
- Minimum Overhead -32 fpm: 105” (2667mm)
- Minimum Overhead -40 fpm: 108” (2743mm)
- Cabin Entrance Width: 32” (813mm)
- Internal Cabin Height: 79” (2007 mm)
- Internal Cabin Diameter: 44” (1118mm)
- External Cylinder Diameter: 36.75” (933mm)
- Rated Load: 500lb (227 kg)
- Capacity: 2-Passengers
- Travel: 2 - 4 Stops
- Total Rise: 38 ft
- Speed: 32 fpm
- Electrical: 220 V - 240V / 5A / Single Phase
- 110v Lighting Circuit
- Machinery: Dual Winding Drums
- Exterior: Aluminum Frame & Polycarbonate Panels
- Minimum Floor to Floor Height: 93.5” (2375mm)
- Minimum Floor Ceiling Height: 81” (2057 mm)
- Minimum Overhead: 105” (2667mm)
- Cabin Entrance Width: 25” (635mm)
- Internal Cabin Height: 79” (2007 mm)
- Internal Cabin Diameter: 32” x 32” (813mm)
